Parameters and Specifications
| specification | TRF36 | TRF36-NO | TRF36-NC | TRF36-S | TRF36-S-NO | TRF36-S-NC | Unit |
| stroke per jaw | 8 | 8 | 8 | 4 | 4 | 4 | mm |
| product weight | 0.7 | 0.8 | 0.8 | 0.7 | 0.8 | 0.8 | kg |
| max gripping distance | 60 | 60 | 60 | 50 | 50 | 50 | mm |
| Theoretical Max. Gripping Force:Opening/Closing | 84P/78P | 84P/- | -/78P | 200P/184P | 200P/- | -/184P | N |
| Air ConsumptionperOpening-Closing Cycle | 0.124 | 0.188 | 0.188 | 0.124 | 0.188 | 0.188 | L |
| Min.spring force | / | 140 | 140 | / | 280 | 280 | N |
| air purge allowable pressure | 0.2~0.5 | 0.2~0.5 | 0.2~0.5 | 0.2~0.5 | 0.2~0.5 | 0.2~0.5 | bar |
| work piece weight | 1.8 | 1.8 | 1.8 | 3.6 | 3.6 | 3.6 | kg |
| opening/cosing time | 0.035/0.035 | 0.03/0.05 | 0.05/0.03 | 0.035/0.035 | 0.03/0.05 | 0.05/0.03 | s |
| Max per finger weight/kg | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | kg |
| Repeat accuracy/mm | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 | mm |
| Air pressure range/bar | 3~8 | 3~8 | 3~8 | 3~8 | 3~8 | 3~8 | bar |
| Air connection feature | M5 | M5 | M5 | M5 | M5 | M5 | |
| Temperature range/℃ | 0~60 | 0~60 | 0~60 | 0~60 | 0~60 | 0~60 | ℃ |
| IP class | 67 | 67 | 67 | 67 | 67 | 67 |
